Single Axle Kit – including Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Springs
600kg springs (3 leaf)
750kg springs (4 leaf)
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
39mm round – Holden LM
bearings 750kg
Single Axle Off-road Kit – including Electric Brakes*
Options Include
Bearings
Chinese / Premium
Springs
1340kg springs (6 leaf)
1400kg springs (7 leaf)
1720kg springs (8 leaf)
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
45mm square – Ford slimline
bearings 1400kg
Majority of finish
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Single Axle Kit – including Mechanical Disc Brakes*
Options Include
Bearings
Chinese / Premium
Springs
1000kg springs (5 leaf with LM axle)
1200kg springs (6 leaf with slimline axle)
1400kg springs (7 leaf with slimline axle)
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 1000kg
45mm square – Ford slimline bearings 1400kg
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers
Tandem Slipper Axle Kit – including Mechanical Disc Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Springs
1600kg springs (5 leaf)
1920kg springs (6 leaf)
2160kg springs (7 leaf)
A 20% safety factor for non-load sharing springs already deducted.
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 1600kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem Slipper Axle Kit – including Hydraulic Disc Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Springs
1600kg springs (5 leaf)
1920kg springs (6 leaf)
2160kg springs (7 leaf)
A 20% safety factor for non-load sharing springs already deducted.
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 1600kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers
Tandem Slipper Axle Kit – including Electric Drum Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Springs
1600kg springs (5 leaf)
1920kg springs (6 leaf)
2160kg springs (7 leaf)
A 20% safety factor for non-load sharing springs already deducted.
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 1600kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem 5 Leaf Rocker Roller Kit – including Electric Drum Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 2000kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem 5 Leaf Rocker Roller Kit – including Mechanical Disc Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Axle
40mm square – Holden LM bearings 2000kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem 5 Leaf Rocker Roller Kit – including Hydraulic Disc Brakes and Lazy Hubs*
Options Include
Bearings
Chinese / Premium
Axle
40mm square – Holden LM bearings 2000kg pair.
45mm square – Ford slimline bearings 2000kg pair.
For long axles, this is a better option – there is less flex.
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Landcruiser and Ford are stronger.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem Rocker Roller Kit – including Electric Drum Brakes*
Options Include
Bearings
Chinese / Premium
Springs
2000kg Springs (5 leaf)
2500kg Springs (6 leaf)
3000kg Springs (7 leaf)
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Landcruiser and Ford are stronger.
5/8-inch U-bolts are required for this kit.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tandem Rocker Roller Kit – including Hydraulic Disc Brakes*
Options Include
Bearings
Chinese / Premium
Springs
2000kg springs (5 leaf)
2500kg springs (6 leaf)
3000kg springs (7 leaf)
3500kg springs (8 leaf)
4000kg springs (9 leaf)
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Stud pattern
Holden HT, HQ or Commodore Ford Landcruiser Landcruiser and Ford are stronger.
Axle
45mm square axle has a maximum rating of 2800kg per pair. 50mm square axle has a maximum rating of 4000kg per pair.
5/8 -inch U-bolts are required for this kit.
Tri-axle Rocker Roller Kit – includes Electric Drum Brakes*
Options Include
Bearings
Chinese / Premium
Springs
3000kg Springs (5 leaf)
3750kg Springs (6 leaf)
4200kg Springs (7 leaf)
5000kg Springs (9 leaf)
Handbrake boat trailer or A-frame? For boat trailers, what width is the drawbar?
50mm
75mm
100mm
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Landcruiser and Ford are stronger.
5/8-inch U-bolts are required for this kit.
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Tri-axle Rocker Roller Kit – includes Hydraulic Disc Brakes*
Options Include
Bearings
Chinese / Premium
Springs
3000kg Springs (5 leaf)
3750kg Springs (6 leaf)
4200kg Springs (7 leaf)
5000kg Springs (9 leaf)
Majority of finish?
Galvanised or Black – some items are not available in galvanised finish, such as hangers.
Stud pattern
Holden HT, HQ or Commodore
Ford
Landcruiser
Landcruiser and Ford are stronger.
5/8 inch U-bolts are required for this kit.
